Product Description
Manufactured from first-class Q355B wearable steel, this extended reach structure undergoes advanced forging processes to resist extreme mechanical stresses in earth-moving operations. The heavy machinery boom assembly is treated to achieve a surface hardness of HRC52-58 with an 8mm to 12mm hardening depth, directly mitigating abrasive wear during river dredging or deep ditch excavation. Integrated with precisely machined bucket cylinders, high-pressure hydraulic hoses, and specialized H-linkages, the entire digging geometry is engineered for optimal payload retention. Furthermore, structural integrity is strictly verified through mandatory welding quality inspection and dimensional testing, preventing micro-fractures under heavy lateral loads.
Application
The two-section long reach boom and arm is engineered for heavy earth-moving jobs where extended working range and structural stability are critical. Available in both two-section and three-section configurations, this assembly performs exceptionally well in deep excavation and waterway maintenance where standard excavator attachments cannot operate effectively.
Typical Applications:
- Construction transportation of sand and concrete materials
- Slope repairing and grading for expressways
- Dredging and desilting operations in river courses
- Earthwork excavation for large building foundations
- Deep ditch trenching and complex earth-moving tasks
What's Included in the Set?
Our excavator long reach boom and arm(stick)include:
- 1 pcs x Boom
- 1 pcs x Arm/stick
- 1pcs x Bucket cylinder
- 1pcs x Bucket, Grab or customized attachmen
- 1set x Bucket Linkages（H Link,I Link）
- 4pcs x Hoses, steel tubes etc
- 6pcs x Pins
Product Parameters
Xiamen Fortune Industrial Co., Limited
Product Name
Q355B Steel Long Reach Boom And Arm For Caterpillar Excavators
Production Standard
OEM installment size
Material
Q355B purchased from first class steel plant
Process
Forging or Casting
Painting Color
Black or yellow or as customers' request
Surface Hardness
HRC52-58, Depth:8mm-12mm
Quality Guarantee
6 months--one year
Certification
ISO9001-9002
Delivery Time
Within 15--25 days after sales contract establishment
Package
Fumigate seaworthy packing and Export Standard Package
Payment Term
TT, L/C, Paypal, Western union,D/P
Application
Crawler Excavator& Wheel Loader&Backhoe&Digger
Why Choose us?
| Caterpillar | Excavator | E320,E320D,E320E, E323, E330,E330D, E336,E345DL, E349DL, E374, E395, E305.5, E308, E312, E315 |
| Caterpillar | Bulldozer | D3, D5H,D5M,D5N, D6,D6H,D6R,D6T,D6M,D6N, D7, D7G,D7H,D7R,D8,D8N,D8R,D8T, D9, D9R,D9N,D9T,D10N,D10T, D11N,D11T |
| Caterpillar | Motor Grader | 120, 140, 160, 18, 24 |
| Komatsu | Excavator | PC55, PC70, PC130, PC200, PC220, PC240, PC300, PC350, PC400, PC450, PC650, PC800, PC1250 |
| Komatsu | Bulldozer | D20,D31, D37, D51, D61, D65EX-12,D65PX-15, D85EX-15EO, D85ESS-2A,D155AX-6, D275, D375, D475, D575 |
| Komatsu | Wheel Loader | WA100, WA150, WA200, WA250, WA320, WA380, WA430, WA470, WA500, WA600, WA800, WA900 |
| Komatsu | Motor Grader | GD405, GD555, GD655, GD675, GD755, GD825 |
| Hitachi | Excavator | ZX55, ZX70, ZX120, ZX130, ZX200, ZX210, ZX240, ZX250, ZX330, ZX350, ZX470, ZX670, ZX870, ZX1200, EX200,EX300,EX400 |
| JCB | Backhoe Loader | 1CX, 2CX, 3CX, 4CX, 5CX |
| JCB | Excavator | JS130, JS145, JS160, JS200, JS220, JS235, JS300, JS330, JS370, JS460 |
| Kobelco | Excavator | SK55, SK75, SK130, SK140, SK170, SK200, SK210, SK210LC-8,SK220, SK250, SK260, SK300, SK330, SK350, SK480, SK500, SK850 |
| Hyundai | Excavator | R55, R80, R110, R140, R160, R180, R210, R220, R250, R290, R300, R330, R360, R380, R430, R480, R520, R800 |
| Shantui | Bulldozer | SD08, SD13, SD16, SD22, SD23, SD32, SD42, SD52, SD90 |
| Shantui | Excavator | SE60, SE75, SE135, SE150, SE210, SE215, SE220, SE240, SE260, SE335, SE370, SE470, SE500 |
| Doosan | Excavator | DX55, DX60, DX80, DX140, DX150, DX170, DX200, DX225, DX235, DX255, DX300, DX340, DX350, DX380, DX420, DX480, DX520, DX530, DX700, DX800 |
| New Holland | Excavator | E18, E26, E33, E37, E55, E60, E75, E135, E145, E175, E215, E230, E260, E305, E335, E385, E485 |
| Daewoo | Excavator | DH55, DH60, DH80, DH130, DH150, DH170, DH200, DH220, DH225, DH258, DH280, DH300, DH320, DH360, DH370, DH420, DH500 |
FAQ
Q1: Do you support custom manufacturing?
A: Yes. We offer OEM production exactly per your drawings or samples. Custom painting colors and specific attachments (buckets/grabs) are also available.
Q2: What materials are used and how durable are they?
A: We use high-performance Q355B wearable steel. The surface achieves HRC52-58 hardness with an 8mm-12mm hardening depth, ensuring excellent wear resistance.
Q3: What is the delivery time and packaging method?
A: Production and delivery take 15-25 days after the sales contract is established. All products use fumigated, seaworthy export packaging for secure shipping.
Q4: What is included in the package and what is the warranty?
A: A complete set includes the boom, arm, bucket cylinder, bucket/attachment, linkages, hoses, and pins. We offer a 6-month to 1-year warranty backed by strict ISO9001 quality inspections.
